Rolex 5512 vs 5513: Which Vintage Submariner Should You Buy in 2026?

The Rolex 5512 vs 5513 debate has puzzled collectors for decades, and with good reason too. These vintage Submariner references look almost similar at first glance, but the differences matter more than you might think. Rolex produced just 17,338 examples of the 5512 compared to 151,449 units of the 5513. There was just one 5512 manufactured for every ten 5513s produced.

The Rolex Submariner 5512 featured chronometer certification. The 5513 did not. This difference affected pricing and dial text, therefore impacting their collectibility today. You need to understand the Rolex 5512 vs 5513 differences to make an informed decision about which vintage Submariner deserves a place in your collection.

Rolex 5512 vs 5513: The Core Differences

Chronometer Certification: The Main Difference

Rolex began producing both references at the same time after 1962. Chronometer certification became the defining difference. The 5512 received COSC-certified movements, while the 5513 never did. This distinction went beyond technical specifications. The 5512’s movement passed accuracy testing for chronometer certification. The 5513 served as the more economical alternative.

Movement Specifications: Cal. 1530, 1560, and 1570

The earliest 5512 models from 1959 housed the non-chronometer Caliber 1530. Rolex then upgraded to the chronometer-rated Caliber 1560 from 1959 to 1965 and followed with Caliber 1570 from 1965 to 1972. The 1570 received hacking seconds functionality in 1972 and powered the 5512 until 1980. The 5513, however, started with Caliber 1530 and transitioned to Caliber 1520. Both remained non-chronometer throughout production.

Dial Text Variations: Two-Line vs Four-Line

Early 5512 examples featured only two lines of text: the depth rating and “Submariner” name. Rolex introduced chronometer-certified movements and two additional lines appeared: “Superlative Chronometer Officially Certified”. This created the four-line dial configuration. The 5513 kept its clean two-line appearance throughout its whole run and displayed only “Submariner” and the depth rating.

Production Timeline: 1959-1980 vs 1962-1989

Rolex manufactured the Submariner 5512 from 1959 until 1980. The 5513 arrived three years later in 1962 and continued until 1989. Both references ran at the same time for 18 years. Buyers had a choice between chronometer precision and value.

Price Differences Then and Now

The 1960s and early 1970s saw the 5513 sell for under $300. This positioned it as an available tool watch rather than a luxury item. The 5512 carried a premium due to its chronometer status. The 5512 commands much higher prices today owing to its rarity and technical achievement.

Physical Design and Specifications Comparison

Case Construction and Dimensions

The Rolex Submariner 5512 and 5513 share similar case specifications. Each measures 40mm in diameter, 47mm lug-to-lug, and 14mm in thickness. This marked a major increase from earlier Submariner models that measured 38mm. The cases feature beveled lugs and the signature Oyster construction. The 5512 came with a 7mm crown that was larger than previous models. These dimensions wear comfortably on wrists of all sizes and contribute to their enduring appeal.

Crown Guard Development: Square, Pointed, and Rounded

The 5512 introduced crown guards to the Submariner lineup in 1959. It became the first Rolex watch with this protective feature. Square crown guards appeared first but proved impractical when wearers adjusted the crown. Only about 100 examples with square guards are known to exist. Rolex transitioned to “eagle beak” crown guards quickly, with less than 30 known examples. Pointed crown guards appeared from 1959 to 1963. Rounded crown guards arrived in 1963 and continued through 1980 on the 5512. The 5513 featured pointed guards at first before adopting the rounded design.

Bezel and Insert Characteristics

Both references feature rotating bezels with black anodized aluminum inserts. The inserts display 10-minute increments and 1-15 demarcations with a 60-minute triangle marker. Inserts from the 1960s feature the “Long 5” characteristic with elongated numerals. The luminous pip wore out or was knocked from the insert over decades of use. Saltwater exposure caused many inserts to fade from black to gray, “ghost,” or dark blue.

Crystal Type and Water Resistance Ratings

Acrylic crystals protected both models. Each reference offered 200m water resistance that matched their dial markings of “200m=660ft” or later “660ft=200m”. The depth rating remained constant throughout production despite the reversed notation.

Rolex 5512 Dial Variations and Collectibility

Gilt Dials vs Matte Black Dials

Rolex Submariner 5512 dial variations began with gilt dials from 1959 to 1966 and transitioned to matte black dials from 1967 to 1980. Gilt dials featured gold-toned text achieved through galvanization, where brass metal beneath black lacquer created a reflective quality. The production process involved treating metal rather than applying paint. Matte dials emerged with pad printing technology that Wilfried Philipp developed around 1965 and offered simpler manufacturing. Gilt dials command premiums because of their shorter production run and striking appearance.

Meters First vs Feet First Depth Ratings

Early matte dial 5512s displayed “200m=660ft” from 1967 to circa 1969. Rolex reversed this to “660ft=200m” around 1969/1970 to increase sales in the US market, where the metric system hadn’t been adopted. Meters first dials feature distinct characteristics: semi-open ‘6’s in depth ratings and ‘SWISS – T < 25’ spanning five minute hash marks.

Maxi Dials and Late Production Models

The Mk. 3 MAXI dial ranks among the rarest matte dials Rolex produced. These late-production dials featured large tritium hour plots that nearly touched 5-minute hash marks. Higher production costs meant that Rolex made only one 5512 for every five 5513s manufactured in the 1970s.

Explorer Dials and Rare Variants

Explorer dial Submariners in the 5512 reference are rare beyond measure. Rolex produced most 5512 Explorer dials for the UK market. These variants resulted from Rolex using excess Explorer dial blanks with Submariner text added.

MilSub 5513: The Military Exception

The British Royal Navy received 1,200 specially modified 5513 references. These MilSub watches featured sword hands and an enlarged encircled ‘T’ above the depth rating, along with 60-minute bezel markings and fixed bar lugs. Three references produced approximately 1,110 MilSub examples, with only approximately 300 known today.

Investment Value and Market Comparison in 2026

Current Market Prices and Availability

Late-production 5513 glossy dial examples start around $10,000. Matte dial 1970s-1980s models range from $9,000 to $15,000. The 1960s gilt dial specimens command $25,000 to $40,000 or higher based on condition. MilSub variants reach six-figure prices. The 5512 starts above $16,000 for 1970s examples with rounded crown guards and matte dials. Square crown guard 5512s sold for over $200,000 in 2013, and a rare Explorer dial 5512 fetched $250,000 in 2020.

Production Numbers: 17,338 vs 151,449 Units

The 9-to-1 production ratio makes the Rolex 5512 vs 5513 price difference substantial. Official Rolex documentation confirms only 17,338 units of the 5512 were manufactured compared to 151,449 units of the 5513. This lack drives premiums for the chronometer-certified reference.

Condition Factors That Affect Value

Pristine, all-original examples sell for 15-30% more than altered models. Heavy polishing removes bevels and sharp edges. Value diminishes by a lot. Original dials command stronger prices than refinished ones, even when typography variations like “meters first” appear.

Original Parts vs Service Replacements

Service parts from authorized Rolex centers decrease collectability despite improving appearance. A worn Submariner with factory-original components values higher than a pristine example with replacement parts. Matching reference numbers, clasp codes and period-correct bracelets add considerable value.

Long-Term Investment Potential

The 5513 qualifies as a “blue chip” piece. Rolex discontinued acrylic crystal Submariners. Younger collectors seeking vintage versions of contemporary sport watches maintain strong demand. Market volatility aside, the Rolex Submariner 5512 vs 5513 comparison reveals both references are sound long-term investments.

Comparison Table

Rolex 5512 vs 5513 Comparison Table

Feature	Rolex 5512	Rolex 5513
Production Period	1959-1980	1962-1989
Total Units Produced	17,338 units	151,449 units
Production Ratio	1 unit for every 10 5513s produced	10 units for every 1 5512 produced
Chronometer Certification	Yes (COSC-certified after 1962)	No (never certified)
Movement Calibers	Cal. 1530 (1959, non-chronometer) Cal. 1560 (1959-1965, chronometer) Cal. 1570 (1965-1980, chronometer with hacking seconds from 1972)	Cal. 1530 and Cal. 1520 (both non-chronometer throughout production)
Dial Text Configuration	Two-line (early models) Four-line (with chronometer certification: “Superlative Chronometer Officially Certified”)	Two-line throughout whole production (“Submariner” and depth rating only)
Case Diameter	40mm	40mm
Lug-to-Lug	47mm	47mm
Thickness	Around 14mm	Around 14mm
Crown Size	7mm	Not mentioned
Crown Guard Evolution	Square (1959, ~100 examples) “Eagle beak” (<30 examples) Pointed (1959-1963) Rounded (1963-1980)	Pointed (at first) Rounded (later production)
Water Resistance	200m (660ft)	200m (660ft)
Crystal Type	Acrylic	Acrylic
Bezel Insert	Black anodized aluminum with rotating bezel	Black anodized aluminum with rotating bezel
Dial Variations	Gilt dials (1959-1966) Matte black dials (1967-1980) Meters first vs Feet first Maxi dials (Mk. 3) Explorer dials (rare, mostly UK market)	Standard variations MilSub variant (1,200 units for British Royal Navy with special modifications)
Original Retail Price (1960s-70s)	Premium pricing due to chronometer status	Under $300
Current Market Price (2026)	Starting above $16,000 (1970s matte dial models) $200,000+ (square crown guard, 2013) $250,000 (rare Explorer dial, 2020)	$10,000+ (late glossy dial) $9,000-$15,000 (1970s-80s matte dial) $25,000-$40,000+ (1960s gilt dial) Six figures (MilSub variants)
Rarity	Much rarer (9:1 ratio vs 5513)	More common
Investment Potential	Sound long-term investment, higher premiums due to rarity and chronometer certification	“Blue chip” piece, strong long-term investment potential

Conclusion

The Rolex 5512 vs 5513 debate ends up being about rarity versus accessibility. The 5512 offers chronometer certification and substantially lower production numbers, commanding premium prices. The 5513 provides authentic vintage Submariner character at more approachable entry points.

Want the rarer piece with superior specs? Choose the 5512. The 5513 delivers better value with classic vintage appeal. Both references represent sound investments in horological history either way.
